Scania Marine Diesel Engine DI13 304M. 662 kW (900 hp)
Specifications:
- Engine speed: 2,300 rpm
- Emission compliance: EU RCD Stage II, US Tier 3 for pleasure craft
- Rating: Pleasure craft
- No of cylinders: 6 in-line
- Working principle: 4-stroke
- Displacement: 12.7 liters
- Weight: 1,285 kg (excluding oil and coolant)
- Oil capacity: 39-45 liters (standard oil sump)
- Electrical system: 2-pole, 24 V DC
Standard equipment
- Scania Engine Management System, EMS
- Extra high pressure fuel injection system, XPI
• Turbocharger
• Saver ring in cylinder liner
• Fuel filter and extra pre-filter
with water separator
• Oil filter, full flow
• Centrifugal oil cleaner
• Oil cooler, integrated in cylinder block
• Oil filler, in cylinder block
• Deep front oil sump with ladder frame
• Oil dipstick, in cylinder block
• Starter motor, 2-pole 7.0 kW
• Alternator, 2-pole 100 A
• Flywheel SAE 14
• Silumin flywheel housing, SAE 1 flange
• Front-mounted engine suspension
• Closed crankcase ventilation
• Sea water pump
• Sea water-cooled charge air cooler
• Heat exchanger with expansion tank
Scania might not be the first name that comes to mind when you think of marine diesels. But that could well change thanks to a powerful, lightweight and efficient new model showcased in a twin-inboard installation powering the new 46-foot Billfish from Viking Yacht Company.
Swedish-based Scania—one of the world’s leading manufacturers of engines for trucks, buses, industrial applications and boats—introduced the DI13 marine diesel to North America earlier this year. That prompted one of the United States distributors for Scania North America, Mack Boring & Parts Co., to put a pair of the 900 hp versions of the DI13 in its new Viking 46BF company boat. Mack Boring christened it Mack 900. Scania Marine Diesel Engine Services Courtesy of Jim Hendricks
