Knowing the correct oil type, engine-oil capacity and filter arrangement is essential when servicing a MAN marine diesel. This MAN marine engine oil type and capacity chart covers popular D2866, D2876, D2840, D2842, D2676, D2868 and D2862 marine engines, while our Marine Diesel Troubleshooting Guide can help diagnose low oil pressure, excessive oil consumption, blue smoke, overheating, loss of power and other marine diesel problems.
MAN Marine Engine Oil Type & Capacity Chart
Quick-reference oil capacities, sump configurations, lubrication recommendations and oil-filter information for popular MAN six-cylinder, V8, V10 and V12 marine diesel engines.
MAN Marine Oil Capacity & Filter Chart
| MAN Marine Engine | Common Oil Capacity / Service Quantity | Oil Filter Arrangement | Recommended Oil |
|---|---|---|---|
| D2866 LE Series | Approx. 18–20 L depending on sump* | Full-flow filtration with two filter cartridges on documented versions | MAN-approved heavy-duty diesel oil meeting the specification required for the engine generation |
| D2876 LE Series | Verify exact LE model, sump and serial number* | Full-flow filtration — verify exact cartridge/application | MAN-approved heavy-duty diesel oil; suitable 15W-40 commonly used where approved |
| D2848 LE Series | Approx. 25–33 L oil-change quantity depending on sump* | Two full-flow paper filter cartridges | MAN-approved diesel engine oil matched to MAN service-product specification |
| D2840 LE Series | Approx. 33–51 L with filters depending on marine sump* | Two full-flow filter cartridges | Approved heavy-duty diesel oil meeting applicable MAN specification |
| D2842 LE Series | 33–35 L typical shallow/deep; up to 73 L with large V70 sump* | Two full-flow paper filter cartridges | MAN-approved heavy-duty diesel oil; viscosity selected for operating temperature |
| D2676 Marine | Verify exact marine model and sump* | MAN full-flow lubrication filtration | Current MAN-approved engine oil meeting engine-generation service specification |
| D2868 V8 Marine | Verify exact LE model and marine oil pan* | Full-flow MAN filtration — serial-number verification required | MAN-approved heavy-duty diesel oil appropriate for modern common-rail engines |
| D2862 V12 Marine | Verify marine configuration; D28 family capacity depends heavily on pan* | MAN full-flow filtration — verify engine serial number | MAN-approved heavy-duty diesel oil meeting current engine specification |
| D2862 Non-Marine Reference | 59 L without filter / 64 L with filter on documented D2862 LE13x* | Full-flow filtration | MAN-approved oil according to current service-product standard |
| D38 Family Reference | 45 L without filter / 49 L with filter* | MAN full-flow filtration | Current MAN-approved heavy-duty diesel engine oil |
IMPORTANT — MAN OIL CAPACITY CAN CHANGE DRAMATICALLY WITH THE OIL PAN:
MAN marine engines were offered with shallow, deep, front-sump and large-capacity oil pans. The engine family alone is therefore not enough information to determine the correct quantity. Always verify the complete MAN model designation, serial number, oil-pan configuration and dipstick before filling the engine.
Capacity note: Older MAN D28 engines provide an excellent example. Depending on model and sump, the oil-change quantity can range from the low-30-liter range to more than 70 liters. Two engines that both carry a D2842 designation may therefore require dramatically different oil quantities.
MAN oil recommendation:
Use an engine oil carrying the appropriate MAN approval or meeting the MAN service-product specification required for the particular engine generation. High-quality heavy-duty diesel oils such as Chevron Delo or Shell Rotella may be appropriate when the specific formulation satisfies the required MAN approval, viscosity and performance specification. Never select oil solely by brand name or viscosity.
What Oil Should You Use in a MAN Marine Diesel?
MAN marine engines span several decades of diesel-engine technology, from mechanically injected D2866 and D2842 engines to electronically controlled common-rail D2676, D2868 and D2862 engines.
Because of that range, there is no single oil specification that should automatically be applied to every MAN marine engine.
SAE 15W-40 has been commonly used in many MAN marine applications where permitted by the engine documentation and operating temperature. Later common-rail engines may require newer lubricant performance standards, making the exact MAN approval more important than simply choosing a familiar viscosity.
Why MAN Oil-Pan Configuration Matters
MAN designed many of its marine engine families for installations with very different vessel layouts. To accommodate those installations, several engines were offered with multiple oil-pan designs.
That creates one of the biggest potential mistakes when looking up MAN oil capacity: assuming the engine model automatically determines the quantity.
Shallow vs. Deep Sumps
An older MAN D2842 can use a shallow or deep sump with an oil-change quantity in approximately the 33-to-35-liter range, while another D2842 configuration fitted with the large V70 pan can require approximately 73 liters during an oil-and-filter change.
Installation Angle Also Matters
Certain MAN documentation provides separate lubrication capacities for engines installed at substantial angles. This is another reason that a generic internet capacity should never replace the engine-specific operator manual and dipstick.
CLASSIC INLINE SIX
MAN D2866 LE
The D2866 is one of MAN’s familiar mechanically injected inline-six diesel families and appeared in numerous commercial and recreational marine installations.
Documented versions use full-flow lubrication filtration with two paper filter cartridges. Published sump capacities for certain versions range from approximately 18 to 20 liters at the maximum mark, depending on the particular pan.
LARGE INLINE SIX
MAN D2876 LE
The D2876 followed the D2866 family and was produced in several marine ratings, including high-output recreational versions.
Because the LE suffix and production generation affect configuration, use the full model number—such as D2876 LE423 or LE433—rather than treating every D2876 as having identical lubrication specifications.
V8 MARINE DIESEL
MAN D2848 LE
The D2848 is a classic MAN V8 marine diesel used in motor yachts and commercial applications.
Published MAN service information shows multiple oil pans, with oil-change quantities around 25 liters for a front deep sump and approximately 33 liters for rear-deep or shallow arrangements on documented versions.
V10 MARINE POWER
MAN D2840 LE
The D2840 is MAN’s V10 member of the classic D28 family. It was produced in several high-output marine configurations and can have very different lubrication capacities depending on the sump.
Factory documentation for certain D2840 models lists approximately 41 liters with a shallow pan, 33 liters with a front deep sump and as much as 51 liters with the larger V48 pan.
CLASSIC MAN V12
MAN D2842 LE
The D2842 V12 became one of the most recognizable MAN engines in European performance yachts and large motor yachts.
Documented configurations include approximately 33 liters with a semi-shallow pan, 35 liters with a deep pan and up to 73 liters with the large V70 oil pan, including the filter change.
MODERN INLINE SIX
MAN D2676 Marine
The D2676 is a modern 12.4-liter inline-six used in commercial marine applications. Current MAN ratings span light-, medium- and heavy-duty operation.
Because duty rating, emissions configuration and oil-pan arrangement can differ, the complete engine type and serial number should be used to determine the final service quantity.
16.2-LITER COMMON-RAIL V8
MAN D2868 Marine
The D2868 is MAN’s modern 16.2-liter V8 common-rail marine engine. Current commercial versions cover power ratings from approximately 600 horsepower in heavy-duty operation to around 1,300 horsepower in light-duty applications.
Modern electronic MAN engines should receive oil meeting the applicable current MAN service-product approval rather than relying on lubricant recommendations written for earlier mechanically injected D28 engines.
24.2-LITER COMMON-RAIL V12
MAN D2862 Marine
The D2862 is MAN’s modern 24.2-liter V12 and is widely used in high-performance yachts and commercial vessels.
Current marine variants are available in ratings reaching approximately 2,000 horsepower. Because the D2862 exists in several duty classes and configurations, confirm the exact LE designation and lubrication arrangement before establishing oil quantity.
MAN Marine Engine Oil Filters
MAN lubrication filtration varies considerably between engine generations. Many older D28 engines use two replaceable paper filter cartridges inside full-flow filter housings, while later electronically controlled engines use newer filter arrangements.
D2840, D2842 and related engines commonly use two full-flow paper filter elements.
D2676, D2868 and D2862 applications should be identified by complete model and serial number before ordering filters.
Do not assume that two MAN engines of the same basic displacement use identical filter elements. Model suffix, production date and lubrication-system configuration can affect the filter application.
FILTER PART-NUMBER NOTE:
MAN part numbers can be superseded and the same engine family may use different filters according to model suffix and production date. Verify the complete engine serial number and inspect the installed filter housing before ordering service parts.
Need MAN Marine Diesel Service?
805 Marine Diesel Mechanic provides MAN oil and filter service, computerized diagnostics, cooling-system maintenance, fuel-system troubleshooting, turbocharger service and marine engine surveys throughout Ventura, Oxnard, Channel Islands Harbor and Santa Barbara.
How to Change the Oil Correctly on a MAN Marine Engine
Warm the Engine Before Draining
Whenever practical, bring the engine to normal operating temperature before extracting or draining the oil. Warm oil flows more easily and carries suspended contaminants out of the lubrication system more effectively.
Confirm the Oil Pan Before Filling
This step is particularly important on MAN engines. Do not determine the fill quantity solely from a broad designation such as D2842 or D2840. Confirm the engine model, oil-pan configuration and applicable service documentation first.
Replace the Complete Filter Set
Older MAN engines using two cartridge-type full-flow filters should have both elements serviced together. On modern engines, identify the complete filter arrangement before starting the oil change.
Fill Conservatively
Initially add less than the expected final capacity. Start the engine, verify oil pressure immediately and inspect the filter housings, oil cooler connections, drain fittings and lubrication hoses for leakage.
Allow Oil to Drain Back
After shutdown, allow enough time for oil in the engine and filter system to return to the sump. Then establish the final oil level using the properly calibrated dipstick.
MAN Oil Analysis & Engine Condition
Oil analysis can be especially valuable on high-output MAN marine engines. Laboratory analysis can identify wear metals, fuel dilution, coolant contamination, soot loading and changes in lubricant viscosity before some problems become obvious during normal operation.
Trending several samples from the same engine provides considerably more useful information than relying on a single test.
Oil analysis is also valuable during a MAN Marine Engine Survey, where lubrication findings can be considered alongside computerized diagnostic data, cooling-system condition, turbocharger operation and sea-trial performance.
Fuel Dilution
Fuel contamination can lower oil viscosity and reduce the lubricant film protecting crankshaft journals, bearings, cylinder components and turbochargers. A rising oil level or abnormal laboratory result should therefore be investigated promptly.
Coolant Contamination
Coolant in the engine oil can cause serious bearing and internal engine damage. Oil analysis can sometimes identify contamination before it becomes obvious on the dipstick or oil filler cap.
MAN Preventive Maintenance
Engine oil and filters are only one part of maintaining a MAN marine diesel. Heat exchangers, raw-water pumps, aftercoolers, turbochargers, fuel filters, coolant, belts, hoses and exhaust systems all affect engine reliability and performance.
High-output MAN engines can place substantial thermal load on their cooling and charge-air systems. Deferred heat-exchanger or aftercooler maintenance can eventually lead to elevated temperatures, reduced performance and more serious engine damage.
For prospective buyers, our MAN Marine Engine Surveys combine visual inspection, computerized diagnostics, sea-trial testing and engine-condition evaluation.
MAN Oil Capacity: Why the Dipstick Still Matters
A published oil-change quantity tells you approximately how much oil to have available for a service, but the calibrated engine dipstick remains the final reference after the lubrication system has been filled.
Residual oil may remain in coolers, hoses and internal passages. Vessel attitude can also affect the apparent sump level. For those reasons, adding the entire published quantity without checking the dipstick can lead to overfilling.
Use it to prepare the correct amount of oil and identify the expected service quantity.
Use it to establish the correct operating level after filters and galleries have been charged.
MAN Factory & Technical References
D2866: MAN documentation for older D2866 engines shows multiple sump configurations and full-flow filtration using two paper cartridges.
D2840: Documented marine configurations show oil-change quantities of approximately 33, 41 and 51 liters depending on sump arrangement.
D2842: MAN marine documentation identifies deep, semi-shallow and large V70 oil pans, with oil-change quantities ranging from approximately 33 to 73 liters.
Modern MAN marine engines: Current MAN marine propulsion families include the D2676 inline-six, D2868 V8 and D2862 V12.
Always use the complete engine designation and serial number when confirming oil capacity, filters and lubrication requirements. On MAN engines, the basic family number alone may not identify the oil pan, duty rating or exact service specification.
MAN Marine Diesel Mechanic
Oil & Filter Service • Computerized Diagnostics • Cooling Systems • Fuel Systems • Aftercoolers • Turbochargers • Marine Engine Surveys
Ventura • Oxnard • Channel Islands Harbor • Santa Barbara
MAN Marine Engine Oil FAQ
Common questions about MAN marine engine oil capacities, oil specifications, filters, D28 engines, modern common-rail MAN engines and correct marine diesel servicing.
What oil should I use in a MAN marine diesel engine?
Use a heavy-duty diesel engine oil meeting the MAN approval or MAN service-product specification required for the exact engine. Viscosity and performance requirements can differ between older mechanically injected D28 engines and newer common-rail MAN engines, so always verify the complete engine model and serial number.
Can I use 15W-40 oil in a MAN marine engine?
SAE 15W-40 is commonly suitable for many MAN marine engines where that viscosity and the oil’s performance specification are approved by MAN. Do not select an oil based on viscosity alone; the lubricant must also satisfy the applicable MAN specification for the engine generation.
Can I use Chevron Delo in a MAN marine diesel?
Chevron Delo can be suitable when the specific Delo formulation meets the viscosity and MAN lubricant requirements for the particular engine. Always compare the product’s current specifications with the requirements for your exact MAN model rather than relying on brand name alone.
How much oil does a MAN D2866 hold?
Oil capacity varies with the sump configuration. Documented D2866 versions show maximum sump capacities around 18 liters with a deep pan and 20 liters with a shallow pan, so the exact engine and oil pan must be identified before filling.
How much oil does a MAN D2876 hold?
The D2876 was produced in multiple marine versions and oil-pan arrangements, so there is not one capacity that should be applied to every D2876. Verify the complete LE designation, engine serial number and sump before determining the oil-change quantity.
How much oil does a MAN D2848 hold?
Documented D2848 versions use different oil pans, with oil-change quantities approximately in the 20-to-27-liter range depending on configuration. Always confirm the exact D2848 model and sump before performing the service.
How much oil does a MAN D2840 hold?
MAN D2840 capacity varies considerably with the oil pan. Documented configurations show oil-change quantities around 33 liters with some shallow or front-deep pans and approximately 73 liters with a large-capacity deep pan.
How much oil does a MAN D2842 hold?
There is no single universal D2842 oil capacity. Depending on model and sump, documented oil-change quantities include approximately 33, 35, 53 and 73 liters, with some industrial configurations even higher. Identify the complete LE model and oil pan before filling the engine.
Why do MAN D2842 oil capacities vary so much?
MAN offered the D2842 with several oil-pan configurations to accommodate different installations and engine angles. Shallow, deep and large-capacity pans can produce dramatically different service quantities even though the basic engine family remains D2842.
How much oil does a MAN D2676 marine engine hold?
The exact D2676 marine oil quantity should be established from the complete engine model, serial number and applicable MAN documentation. Do not transfer an oil capacity from another D2676 application without confirming the marine sump configuration.
How much oil does a MAN D2868 V8 marine engine hold?
The D2868 exists in several marine ratings and configurations, so the complete LE designation and serial number should be used to determine its oil capacity. The calibrated dipstick remains the final reference after the filter and lubrication system have been filled.
How much oil does a MAN D2862 V12 marine engine hold?
D2862 capacity depends on the exact engine and application. A documented D2862 LE13x configuration lists approximately 59 liters without the filter and 64 liters with the filter, but that figure should not automatically be applied to every marine D2862.
Why is the MAN engine serial number important during an oil service?
The serial number helps identify the exact engine configuration, production generation, service parts and applicable lubrication information. This is particularly important with MAN engines because the same basic family can have different sumps, filters and oil capacities.
Should I fill a MAN engine with the entire published oil capacity at once?
No. Add slightly less than the expected service quantity initially, start the engine, confirm oil pressure and allow the filters and galleries to fill. After shutdown and adequate drain-back time, establish the final level with the calibrated dipstick.
Can overfilling a MAN marine engine cause problems?
Yes. Excessive oil can contribute to crankshaft aeration, increased crankcase pressure, oil carryover and abnormal oil consumption. Because MAN sump capacities can vary substantially, never assume that a capacity from a similar engine is correct for your installation.
How many oil filters does an older MAN D28 engine use?
Many older MAN D28 engines use a full-flow lubrication system with two replaceable paper filter elements. The exact filter cartridges should still be verified by complete engine model and serial number before ordering parts.
How often should the oil and filters be changed on a MAN marine engine?
The correct interval depends on the engine model, oil specification, operating hours and duty cycle. Follow the maintenance schedule for the exact MAN engine rather than applying a universal interval across all D28 and modern common-rail models.
Is oil analysis worthwhile on a MAN marine engine?
Yes. Laboratory oil analysis can identify wear metals, fuel dilution, coolant contamination, soot loading and changes in viscosity. Trending samples is particularly valuable on high-output engines and during a MAN Marine Engine Survey.
What does a rising oil level in a MAN marine engine mean?
A rising crankcase level can indicate contamination rather than additional engine oil. Fuel dilution and coolant contamination should be investigated promptly because either can reduce lubricant protection and potentially cause serious internal engine damage.
What should be checked during a MAN marine engine oil service?
In addition to changing the oil and filters, inspect for oil leaks, verify oil pressure, examine hoses and filter housings and look for signs of fuel or coolant contamination. MAN engines should also receive scheduled cooling-system, aftercooler, turbocharger and fuel-system maintenance.
